products details

Created with Pixso. Home Created with Pixso. Products Created with Pixso.
Radio Shuttle Rack
Created with Pixso.

High-Density Radio Shuttle Racking System for Cold Storage

name

High-Density Radio Shuttle Racking System for Cold Storage

Brand Name: Peterack
Model Number: PT-IS
MOQ: 5000 kilograms
Price: US $ 0.88 kilograms 5000
Payment Terms: T/T
Supply Ability: 20000kg/Month
Detail Information
Product Description
Detail Information
Place of Origin:
Jiangsu,China
Certification:
CE
Racking Type:
High-Density Radio Shuttle Racking System
Compatible Pallet Size:
Customizable (e.g. 1200×1000mm / 1200×800mm)
Load Capacity:
Up To 1500kg Per Pallet (customizable)
Racking Height:
Customizable (typically 3m To 12m)
Lane Depth:
Single Or Double Entry, Up To 40 Pallet Positions Per Lane
Shuttle Type:
Electric Shuttle, Supports Remote Or Automatic Operation
Control System:
Remote Control / WMS Integration / Mobile App (optional)
Temperature Range:
-30°C To +45°C (suitable For Cold Storage)
Material:
High-strength Q235/Q355 Cold-rolled Steel, Powder-coated Finish
Safety Features:
Emergency Stop, Anti-collision Bars, Pallet Detection Sensors
Packaging Details:
Carton packaging; Wooden pallets with wrapping film for bundling
Supply Ability:
20000kg/Month
Highlight:

cold storage radio shuttle rack

,

high-density radio shuttle racking

,

radio shuttle rack system

Product Description
Heavy Duty Automatic Shuttle Pallet Rack Radio Shuttle Racking System
Product Specifications
Attribute Value
Racking Type High-Density Radio Shuttle Racking System
Compatible Pallet Size Customizable (e.g. 1200×1000mm / 1200×800mm)
Load Capacity Up to 1500kg per pallet (customizable)
Racking Height Customizable (typically 3m to 12m)
Lane Depth Single or double entry, up to 40 pallet positions per lane
Shuttle Type Electric shuttle, supports remote or automatic operation
Control System Remote control / WMS integration / Mobile App (optional)
Temperature Range -30°C to +45°C (suitable for cold storage)
Material High-strength Q235/Q355 cold-rolled steel, powder-coated finish
Safety Features Emergency stop, anti-collision bars, pallet detection sensors
Product Overview
Intensive Shuttle Rack - A high-density storage solution designed for efficient warehouse operations.
High-Density Radio Shuttle Racking System for Cold Storage 0
High-Density Radio Shuttle Racking System for Cold Storage 1
Product Details
Product Name Storage Racking
Style Intensive Shuttle Rack
Brand Peterack
Colour Blue, white, orange, green, etc.
Material Steel
Place of Product Jiangsu Province, China
Feature Corrosion Protection
Packing Export Package
Size Customizable
Application Widely used in light industries
The shuttle vehicle in storage logistics equipment operates in two forms: shuttle vehicle inbound/outbound storage system and shuttle vehicle storage system. It moves in a round-trip or looped manner on fixed tracks, transporting goods to designated locations or connecting equipment. The system features an intelligent sensing system that automatically remembers origin positions and includes an automatic deceleration system.
High-Density Radio Shuttle Racking System for Cold Storage 2
High-Density Radio Shuttle Racking System for Cold Storage 3
High-Density Radio Shuttle Racking System for Cold Storage 4
High-Density Radio Shuttle Racking System for Cold Storage 5
High-Density Radio Shuttle Racking System for Cold Storage 6
Upright Parameters
Specification (mm) Thickness (mm) Loading (kg)
W80*D60 1.8-2.0 4000-6000
W85*D67 1.8-2.3 7500-12500
W90*D60 1.8-2.5 8000-10000
W90*D70 1.8-2.5 10000-12000
W100*D70 2.0-2.5 11000-14000
W120*95 2.3-3.0 17000-21000
High-Density Radio Shuttle Racking System for Cold Storage 7
High-Density Radio Shuttle Racking System for Cold Storage 8
High-Density Radio Shuttle Racking System for Cold Storage 9
High-Density Radio Shuttle Racking System for Cold Storage 10
High-Density Radio Shuttle Racking System for Cold Storage 11
High-Density Radio Shuttle Racking System for Cold Storage 12
Customer Feedback
High-Density Radio Shuttle Racking System for Cold Storage 13
High-Density Radio Shuttle Racking System for Cold Storage 14
Exhibition
High-Density Radio Shuttle Racking System for Cold Storage 15
High-Density Radio Shuttle Racking System for Cold Storage 16
High-Density Radio Shuttle Racking System for Cold Storage 17
High-Density Radio Shuttle Racking System for Cold Storage 18
Frequently Asked Questions
Q: Are you a factory or trading company?
A: We are a manufacturer. Our factory has been specializing in warehouse racks and different kinds of display stands for 15 years.
Q: Where is your factory located?
A: Our factory is located in Nanjing.
Q: What is your delivery time?
A: In general, within 20 days, but it also depends on the order quantity and shelves design.
Q: What is the trade term?
A: Generally, we will use EXW or FOB. Other terms can be negotiated.
Q: Could you produce according to customers' design?
A: Sure, we have very rich experience in customizing shelves.
Q: Do you produce shelf with different kinds of materials?
A: Yes, our products are mainly made of metal but we also produce accessory shelves or displays with wood, titanium alloy, acrylic, glass, etc.
Q: What are main rack and add on rack?
A: The difference between these two kinds of racks is upright. Main rack is the start rack with 2 uprights and add on rack is the continue rack with only 1 upright. For example, if there are 10 wall racks against the wall, the structure will be 1 main rack + 9 add on racks.
Q: What is the manner of packing?
A: Generally, shelves are flat packed by air bubble film/film in standard export cartons. Other packing like wooden box are available to clients' requirement.
