Double Deep European Style Selective Pallet Rack 3000kg Capacity Verifiable Factory Custom Warehouse Storage Rack

Double Deep European Style Selective Pallet Rack - High Density Warehouse Storage

The WR-DDR-3000 double deep pallet rack maximizes storage density by placing two rows of pallets back-to-back, accessed from a single aisle using a deep-reach forklift. This European style racking system increases storage capacity by up to 40% compared to standard selective racking, making it ideal for warehouses where space is at a premium.

Key Features

• Double Deep Configuration: Two pallet positions deep per bay, achieving up to 40% more pallet storage in the same footprint compared to single-deep selective racking.
• European Design Standards: Engineered to meet FEM 10.2.02 and EN 15512 racking standards, ensuring structural integrity under heavy industrial loads.
• 3000kg per Beam Level: Heavy duty beam profiles support up to 3000kg uniformly distributed load per pair, accommodating standard EUR and industrial pallets.
• Verifiable Factory Production: Manufactured in an ISO 9001:2015 certified facility. Complete production traceability with material certifications and weld inspection records available.
• Boltless Beam Connection: Auto-engaging safety lock mechanism with dual-tab design prevents accidental beam dislodgement during forklift operations.
• Durable Powder Coated Finish: Multi-stage corrosion protection including alkaline degreasing, zinc phosphating, and electrostatic epoxy powder coating baked at 200°C.
• Seismic Rated Design: Available with reinforced base plates and row spacers for installations in seismic zones, compliant with local building codes.

Technical Specifications

Custom Warehouse Rack Manufacturing

We provide full customization for double deep racking systems — from load calculations and layout design to material selection and color matching. As a verifiable factory with in-house engineering, we deliver complete racking solutions including site-specific structural analysis and installation guidance. Contact us with your warehouse dimensions for a free layout proposal.
